Technical service report

Fill in the line conditions and shot test results before and after an adjustment, then print the report or copy it into your messaging app. Your entries stay on this device.

Technical Services Report

Main issue:

Customer name:

Location:

Date:

Environment details

Ambient temperature: (°C)

Weather condition:

Sunny Cloudy Rain

Processing condition

Polyol name:

Production date:

Machine length: m

Panel type:

1in 2in other

Before

Line temp.: (°C) Line speed: m/min Pol/Iso temp.: / (°C) Test time: s Polyol weight: g Iso weight: g Output: g/s Consumption: g/m Ratio I/P:

Bagshot:

1. CT/GT/TFT= 2. CT/GT/TFT= 3. CT/GT/TFT= FRD: kg/m3

Bagshot appearance and panel issue:

After

Line temp.: (°C) Line speed: m/min Pol/Iso temp.: / (°C) Test time: s Polyol weight: g Iso weight: g Output: g/s Consumption: g/m Ratio I/P:

Bagshot:

1. CT/GT/TFT= 2. CT/GT/TFT= 3. CT/GT/TFT= FRD: kg/m3

Bagshot appearance and panel issue:

What to check

Are the polyol and isocyanate (iso) tank heaters working well? Is the mixing head clean before use? Are the polyol and isocyanate (iso) filters clean? Is the air pressure sufficient and dry? Check the metal panel surface temperature at the mixing head.

Photos and videos list

Video:

1. Working spraying head

Photos:

1. Cutting edge

2. Surface

3. Panel edges

4. Bagshot foam (half-cut)

5. Close-up of the problem part/area

6. Polyol drum label

Please send photos and videos through your messaging app along with this printed report.
